WPS-CA/EP76 3-Inch Submerged Pulse Valve WATSON Solenoid Valve Pulse Jet Valves AC220V DC24V

Product Description:

Connection Specification: Features a 3-inch submerged design, suitable for installation inside air receivers (air tanks).

Operating Pressure Range: Typically ranges from 1.5 bar to 8 bar.

Operating Temperature:

• Standard version: Suitable for an ambient temperature of -40°C to +100°C.
• High-temperature version: Operable in an environment of -20°C to +200°C.

Protection Class: Achieves IP65, providing dust resistance and protection against water spray from certain directions.

Weight: Approximately 11 kg.

Technical Principle: Adopts pulse electromagnet technology. Through the rapid attraction and release of the pulse electromagnet, high-speed pulsed airflow is generated, enabling rapid on-off control of fluid and regulation of flow direction.

Material Composition:

• The 3/4-inch upper cover is generally made of die-cast aluminum.
• The 3-inch submerged valve body is also constructed from die-cast aluminum.
• The diaphragm is usually made of materials such as TPE (Thermoplastic Elastomer) (selected based on specific working conditions).

Key Technical Terminology Supplementary Explanation:

• Submerged Pulse Valve: A specialized pulse valve installed inside the air receiver (instead of being mounted externally). It directly releases pulsed air into the filter bag area, reducing airflow resistance and improving dust-cleaning efficiency, which is widely used in large-scale baghouse dust collectors.
• Die-Cast Aluminum: A metal processing material formed by injecting molten aluminum into a mold under pressure. It has the advantages of high structural strength, good dimensional accuracy, and lightweight, making it suitable for manufacturing valve bodies and covers that require both pressure resistance and portability.
• TPE (Thermoplastic Elastomer): A flexible material combining the elasticity of rubber and the processability of plastic. It exhibits excellent wear resistance, aging resistance, and temperature adaptability, making it a common choice for pulse valve diaphragms (especially in medium-temperature working conditions).
• Air Receiver (Air Tank): A pressure vessel in the dust collector system used to store compressed air. Installing the submerged pulse valve inside it ensures stable air pressure during the pulse blowing process, avoiding pressure fluctuations that affect cleaning performance.

Technical Parameters:

Applications:

Product Application Occasions and Scenarios for the Solenoid Valve Pulse Dust Removal Valve - WATSON WPS-CA/TG76

The Solenoid Valve Pulse Dust Removal Valve, also known as the Right Angle Pulse Valve, by WATSON (Model: WPS-CA/TG76) is a versatile and essential component in various industrial applications. With CE certification and a minimum order quantity of 1, this high-quality valve offers reliable performance and durability.

Product Attributes:

• Brand Name: WATSON
• Model Number: WPS-CA/TG76
• Certification: CE
• Minimum Order Quantity: 1
• Price: Negotiation
• Packaging Details: Carton / As The Clients Require
• Delivery Time: 1-7 Work Days After Payment
• Payment Terms: T/T, Western Union, Paypal
• Supply Ability: 5000 Pieces/1 Month
• Temperature: -25 To +80℃
• Media: Air
• Power: Pneumatic
• Port Size: 3'' Inch

Due to its robust construction and efficient operation, the Solenoid Valve Pulse Dust Removal Valve is suitable for a wide range of applications. Some of the common product application occasions and scenarios include:

1. Industrial Dust Collection Systems: The pulse valve is ideal for controlling the flow of air in dust collection systems used in industries such as cement plants, power plants, and metal processing facilities.

2. Environmental Protection Equipment: The valve plays a crucial role in pulse-jet baghouse dust collectors, ensuring effective and continuous dust removal for environmental protection equipment.

3. Powder Coating Systems: In powder coating operations, the right angle pulse valve assists in the efficient cleaning of filters and maintaining the overall performance of the system.

4. Grain Handling Facilities: For grain handling facilities and agricultural processing plants, the pulse valve helps in controlling air flow and maintaining clean and safe working environments.

With its reliable performance, easy installation, and compatibility with various media and temperature ranges (-25 to +80℃), the Solenoid Valve Pulse Dust Removal Valve from WATSON is a versatile solution for diverse industrial applications. Whether it's for new installations or replacements, this valve ensures efficient and reliable operation.

Packing and Shipping:

Product Packaging:

The Pulse Jet Valves are carefully packaged in sturdy cardboard boxes to ensure safe transportation. Each valve is wrapped in protective material to prevent any damage during shipping.

Shipping:

We offer fast and reliable shipping services for the Pulse Jet Valves. Orders are typically processed and shipped within 1-2 business days. Customers can choose their preferred shipping method at checkout, including standard or expedited shipping options.
